Xilica XP-4080

Xilica XP-4080: 4 input, 8 output DSP for crossover, room and speaker EQ duties

Designed and engineered in Canada, the Xilica XP provides a comprehensive set of digital signal processing (DSP) functionality based on 24 bit / 96Hz converters and 40 bit floating point algorithms. Available DSP routines include IIR crossover filters, parametric EQ, graphic EQ, delays, levels, matrix mixing and polarity. The result is best in class audio and DSP performance that is used by a select band of “in the know” speaker companies including Procella Audio and Legacy Audio.



DSP Capabilities:

  • Matrix Mixer – any input to any output
  • Crossover – 2 for each input and output, from 6-48dB/Oct with choice of Bessel, Butterworth, Linkwitz-Riley types
  • Flexible EQ – 8 band for each input and output with choice of parametric, high shelf. low shelf and phase correction. Per EQ bypass
  • Graphic EQ – 31 band, 1/3rd octave EQ for each input with global bypass
  • Gain per input and output
  • Mute per input and output
  • Polarity per input and output
  • Delays – up to 640ms per input and output



Specifications:

  • 24bit 96kHz converters with internal 40 bit DSP
  • XLR inputs and outputs
  • Setup via front panel controls or via XConsole software which runs on both Windows (PC) and OSX (Mac)
  • Front panel button for per channel muting
  • 2 line LCD screen
  • USB, RS232 and ethernet control
  • Designed in Canada
  • 1u rack mount chassis
  • 2 year warranty

Alternative Xilica processors:

Xilica also manufacture the XP-2040 (2 input, 4 output) which offers more inputs and outputs and the XD-4080 which provides linear phase FIR and digital inputs/outputs.



XD models offer the following upgrades over the XP:

  • Linear phase FIR crossovers
  • Digital input / output
  • 4 line LCD screen
  • Dedicated per channel front panel button for access to DSP settings
